Bosch Laser Level

Why this product

Built for the progress you want.

Battery voltage 18 Working range with receiver up to 600 m (Diameter) Working range with receiver, sign up to Working range with receiver, value 600 Working range with receiver, appendage (Diameter) Working range without receiver up to 60 m (Diameter) Working range without receiver, sign up to Working range without receiver, value 60 Working range without receiver, appendage (Diameter) Operating time (max.) 70 h 60 h Operating temperature -10 – 50°C Operating temperature, up to 50 Operating temperature, from -10 Storage temperature -20 – 50°C Storage temperature, up to 50 Storage temperature, from -20 Laser diode 630 – 650 nm, < 1mW Laser class 2 Accuracy ± 3.0 mm at 30 m* vertical (*plus use-dependent deviation) ± 1.5 mm at 30 m* horizontal (*plus use-dependent deviation) Projection 1 x 360° line Rotation speed 150/300/600 min−1 Self-levelling range ±8.5% (±5°) Tripod thread 2 x 5/8" Dust and splash protection IP 68 Battery 4 x D cell batteries 18 V Li-ion battery Compatible laser receivers LR 60 Length x width x height 327 x 188 x 278 mm Long version part 1 Heavy duty, jobsite-proof – the robust GRL 600 CHV Professional endures even the harshest environments. Its sturdy design offers impact protection and has an IP68 rating against dust and water – including the battery compartment for highly flexible work in bad weather conditions. It provides convenient connectivity, enabling more focused work with less wasted time. Operating the tool is intuitive thanks to its screen and access to the levelling remote app that visualises all functions, including a dual slope setting, to save valuable time. This highly accurate laser has a long runtime, both with the 18V battery system and alkaline batteries included for continuous working. Long version part 2 Use this tool for exterior applications when determining cut-and-fill excavation work, concrete forms, landscaping, and façade work. Long version part 3 The GRL 600 CHV also features a high-quality receiver with a 125-mm reception area, a dual-sided display, and an offset feature in millimetres. Calibrating the tool is quick and easy – follow the step-by-step instructions via the intuitive app to save time and resources and ensure accurate results on every job. Use the handy 'mask mode' available in the app to avoid reflection and interference with other devices on the jobsite.
