Understanding itel inverters
PV, batteries and solar panels—explained.
Compare nine itel inverters on CDcare, understand PV and MPPT limits, and find battery and solar-panel options for a properly matched system.
Loading the interactive system planner…
A system that fits together.
Choose an inverter. We’ll suggest a battery combination and one solar-panel option, with a reason for each. Change the battery quantity to explore longer backup, or open the alternatives to compare.
Recommendations are planning starting points. Your actual loads, exact equipment labels and installation determine the final system.
Choose your inverter
Match your battery
Approved parallel connection keeps the voltage the same and adds storage. Two batteries do not double the inverter’s power.
Compare battery options
Batteries are arranged from smallest to largest by storage per unit. Tap a row to choose. Recommended combinations include a suggested quantity, which you can change above. kWh measures stored energy; amps describe continuous output.
The 32kWh option includes published current and parallel ratings. Match the installed BMS protocol and charging settings to the supplied inverter and battery.
Understand the backup-time calculation
Battery-only runtime = nominal storage × 80% usable energy × 90% conversion efficiency ÷ AC load. No solar or mains contribution is assumed. The current check compares required DC current at nominal voltage and at the published minimum battery voltage with both the combined battery rating and the inverter’s maximum discharge current. If only the nominal check passes, the displayed time is labelled an energy estimate; the load can stop earlier as voltage falls.
Battery voltage falls during use. Starting surges, inverter idle use, ageing, temperature and unequal current sharing can shorten runtime. Even when the low-voltage check passes, BMS derating, the configured reserve and installation conditions can reduce usable output. A larger bank cannot override an inverter’s own current limit.
Add your solar panels
Compare other solar panels
These are catalogue alternatives. A higher wattage panel is not automatically a better electrical match.
Why this panel quantity?
This starting estimate takes the larger of two targets: an array nameplate rating equal to 50% of the inverter’s kW rating, or enough panel capacity to replace 80% of the selected battery bank’s nominal energy over 4 equivalent peak-sun-hours with 75% DC solar availability and 95% battery charging efficiency. It rounds up to whole panels, then chooses a quantity within the PV wattage ceiling and the available nominal voltage/current screen. If those limits prevent the target, it shows a smaller array and explains the shortfall. For the documented Jinko 625W panel, the screen also checks Voc at a reference cell temperature of 10°C. This is not a site temperature assumption; an installer must replace it with the design minimum and apply voltage tolerances. Unknown panel suffixes remain energy illustrations.
The 50% target is an editorial starting point for comparing systems, not a manufacturer rule. Four peak-sun-hours is a scenario, not four clock hours or a forecast for your roof. Weather, shade, orientation and daytime loads change the required array. This estimate excludes energy consumed while charging and does not approve a string layout.
Final panel count and string layout must meet MPPT start-up and operating voltage, cold Voc, operating and short-circuit current limits, bifacial conditions and charging limits. The installer may need to change this starting quantity.
Where does each cable go?
Follow the arrows, then tap a part to understand it. Panels go to PV, batteries go to BAT, and appliances go to the protected AC output.
This is a map of what connects to what, with a teaching example where panel data is available. It is not a terminal drawing or an installation sequence. The installer must specify cable sizes, fuse/breaker ratings, polarity, string layout and earthing for the exact equipment and site.
Which “cutout”, breaker and protection does this system need?
| Part | Plain meaning | What the installer must select |
|---|---|---|
| PV DC isolator | Disconnects the solar input for the required work. It is not automatically a fuse. | PV-rated DC voltage, current, poles and switching duty for the final strings. Panels and upstream cables remain live in sunlight. |
| PV string fuses / DC breakers, where required | Protect against excessive current or backfeed into a string. | Need and rating depend on parallel strings, module maximum series-fuse rating, corrected current and cable capacity. |
| Battery fuse / suitable DC breaker and isolator | Protects the battery cable and permits isolation. Each parallel branch needs the protection specified by the design. | DC voltage, continuous current, surge coordination, cable capacity and enough fault-interruption capacity for the battery bank. Follow the battery manual for placement and polarity. |
| AC breaker and RCD/RCBO | The breaker addresses overcurrent. An RCD detects leakage; an RCBO combines both functions. | Input and output circuit ratings, fault protection, the required RCD type and the correct neutral/earth arrangement for this inverter. |
| PV DC and AC surge protection (SPDs) | Limits short voltage surges on the relevant circuits. It does not replace a breaker or an external lightning system. | Correct DC/AC device, voltage rating, Type 1/2 requirements, backup protection, placement and short bonding paths, coordinated with the building’s lightning design. |
An AC-only breaker is not a battery or PV cutout. The inverter’s kW rating alone cannot determine a safe fuse or cable size.
Try series and parallel: same four panels, different voltage and current
Same four panels. Different electrical result.
Four Jinko 625W panels, using the JKM625N-66HL4M-BDV datasheet at standard test conditions. This teaching example is separate from the combination selected above.
Educational circuit only: fuses, isolators, earthing, surge protection and actual connector routing are omitted. This is not an approved layout for your selected inverter.
Design references: IEC PV-array design scope · DC wiring and fault protection · DEHN: rooftop PV lightning and surge protection. These support the principles; itel manuals govern the exact equipment.
Run appliances. Refill the battery.
Panels can power appliances through the inverter and use the remaining energy to charge the battery. See how a daytime load changes the time needed to recharge from 20% to 100%.
Use measured average watts, allowing for appliances that cycle on and off. Four peak-sun-hours is a comparison scenario, not a local sunshine forecast.
How the charging estimate works
A good solar system starts with your appliances, your backup needs and the equipment’s exact model numbers. Buying the biggest inverter on the page is not enough: the battery must supply the load, and the panels must fit the inverter’s solar-input limits.
This guide compares the nine standalone itel inverter models listed for sale on CDcare at the time of research. It explains their PV inputs, the itel battery families to consider and five solar-panel options you can explore on CDcare. It does not attempt to list every itel model sold worldwide. Specifications were checked on 9 October 2026; the supplied unit’s label and matching manual take precedence.
First, understand these three numbers
A 6kW inverter and a 5.12kWh battery describe two different things. The first is a power rating; the second is an energy rating. Neither number alone guarantees how many air conditioners you can use or how many hours you will get. Appliances have different running power, and fridges, pumps and compressors can demand extra power when starting.
Compare the itel inverters on CDcare
Tap a model to open its product page for the current price and available purchase options. Wi-Fi labels can appear in store names; use the base model and revision on the unit when checking a datasheet.
| Model on CDcare | AC output / phase | Battery family | Max PV array power | MPPT inputs |
|---|---|---|---|---|
| IPV-1K512U | 1.5kW / single phase | 12V | 0.65kW | 1 MPPT · 20A |
| IPV-4K24U Pro | 4kW Pro / single phase | 24V | 6kW | 1 MPPT · 15A |
| IPV-6K48U Pro | 6kW Pro / single phase | 48V | 8kW | 1 MPPT · 27A |
| IHY-6K6L1C | 6.6kW / single phase | 48V | 13.2kW | 2 MPPT · 20A + 20A |
| IPV-8K48T | 8kW / single phase | 48V | 16kW | 2 MPPT · 30A + 20A |
| IHY-8KL3 | 8kW / three phase | 48V | 16kW | 2 MPPT · 18A + 18A |
| IPV-11K48T | 11kW / single phase | 48V | 16.5kW | 2 MPPT · 30A + 20A |
| IPV-12K48U | 12kW / single phase | 48V | 16kW | 2 MPPT · 27A + 27A |
| IHY-12KL3 | 12kW / three phase | 48V | 24kW | 2 MPPT · 36A + 18A |
Read the exact suffix. The 6kW row is the Pro model. The older IPV-6K48U has a different PV specification. The two 8kW models and two 12kW models also differ: one is single phase and the other is three phase.
Technical references: itel 1kW / 1.5kW / 3kW datasheet · itel 4kW Pro / 6kW Pro datasheet · itel IHY-6K6L1C datasheet (Transsion storage) · itel IPV-8K48T manufacturer sheet (ENF mirror) · itel IPV-11K48T manufacturer sheet (Solar Guide mirror) · itel IPV-8K48U / IPV-12K48U datasheet · itel IHY-8KL3 / IHY-12KL3 datasheet
The supplied Nigeria range also includes the 3kW IPV-3K24UPRO with a 4.5kW PV ceiling. It is not in this active-product selector while the older inactive 3kW listings are being reconciled. Its Pro specification must not be replaced with the older IPV-3K24U specification.
What does PV mean?
PV means photovoltaic: the solar panels convert sunlight into electrical energy. The inverter’s solar charger uses that energy to support the connected loads and charge the battery, within the operating mode and limits of the system. At night, the panels are not producing power; your backup then depends on stored energy or another available supply.
The panel label is a laboratory rating, normally expressed in watts-peak. A 625W panel does not produce 625W throughout the day. Sunlight, roof orientation, shading, dirt, temperature and electrical losses all affect real output. Bifacial panels can also collect light from the rear; their additional output depends on the installation, not a fixed bonus available on every roof.
For example, the IPV-11K48T is an 11kW AC-output inverter with a maximum 16.5kW PV-input specification. The larger solar number does not turn it into a 16.5kW AC inverter. Likewise, a 16kW solar-input rating is not a promise of 16kWh generated every hour.
Technical references: itel IPV-11K48T manufacturer sheet (Solar Guide mirror)
MPPT, voltage and current: why panel watts are only the beginning
MPPT means Maximum Power Point Tracking. It adjusts the electrical operating point of a panel string to harvest available power. Two independent MPPTs can help manage two properly designed panel groups with different conditions; they do not remove voltage or current limits.
| Exact model | MPPT operating range | Absolute PV voltage ceiling |
|---|---|---|
| IPV-1K512U | 15–120V | 130V |
| IPV-4K24U Pro | 85–450V | 500V |
| IPV-6K48U Pro | 85–450V | 500V |
| IHY-6K6L1C | 60–425V | 500V |
| IPV-8K48T | 75–500V | 535V |
| IHY-8KL3 | 200–800V | 1000V |
| IPV-11K48T | 75–500V | 535V |
| IPV-12K48U | 85–450V | 500V |
| IHY-12KL3 | 200–800V | 1000V |
The MPPT range is the operating window, while the maximum PV voltage is a ceiling that must not be exceeded. Start-up voltage is a separate check. An installer also checks the voltage range needed to reach full rated power, particularly on the three-phase models.
In a series string, panel voltages add while current stays roughly at the level of one panel. When suitable strings are paralleled, their currents add. Cold weather raises open-circuit voltage (Voc); hot panels can reduce operating voltage (Vmp). String design must account for both, the number of inputs, each MPPT’s operating-current rating, its short-circuit-current limit, and bifacial gain.
A panel-count illustration: eight 625W modules total 5,000W, or 5kWp. That arithmetic does not approve the wiring. If the exact module were JKM625N-66HL4M-BDV, its 15.29A operating current already exceeds the 4kW Pro’s 15A input rating, even before adding a second parallel string.
Technical references: itel 4kW Pro / 6kW Pro datasheet · itel three-phase installation manual · Jinko JKM605–630N-66HL4M-BDV F6 sheet
Which CDcare solar panels can you consider?
| Panel on CDcare | What to check |
|---|---|
| Jinko 590W bifacialExact factory suffix to confirm | A candidate to assess for the 650W PV model; check the delivered module label, including bifacial allowance. Also assess for larger systems. |
| JA 625W bifacialJAM78D40; suffix to confirm | Potential lower-current option for the 4kW Pro. The listing suffix differs from the manufacturer sheets located; approve the exact label first. |
| Jinko 625WJKM625N-66HL4M-BDV | 15.29A operating current at STC. This exceeds the 4kW Pro’s 15A input rating, so do not assume it is a direct match. |
| JA 720W bifacialJAM66D46-720/LB | 17.48A at STC; bifacial conditions raise current. Exceeds the 1.5kW model’s PV power ceiling and the 4kW Pro’s 15A input rating. |
| Jinko 725W bifacial66HL5 family; suffix to confirm | The manufacturer’s JKM725N-66HL5-BDV sheet gives 17.69A at STC. Confirm that exact supplied suffix before using its electrical values. |
For the 1.5kW IPV-1K512U, itel specifies only 650W maximum PV input. A 720W or 725W module already exceeds that power rating. A single 590W or 625W module is only a candidate for assessment: verify the exact voltage, current, tolerance and bifacial treatment against the inverter manual. Two 590W modules total 1,180W, so they must not be presented as a standard match to a 650W-input model.
For the 4kW Pro, pay special attention to its 15A MPPT input. For the larger models, a higher PV rating still does not mean every high-wattage panel or string arrangement will work. In particular, the JA 720W module rises from 17.48A at STC to 19.30A under the manufacturer’s BNPI bifacial conditions; that is material when considering an 18A tracker. Ask for a written string design for the actual modules supplied.
Technical references: itel 1kW / 1.5kW / 3kW datasheet · itel 4kW Pro / 6kW Pro datasheet · JA Solar JAM78D40 600–625/MB sheet · Jinko JKM605–630N-66HL4M-BDV F6 sheet · JA Solar JAM66D46 LB sheet · Jinko JKM710–735N-66HL5-BDV sheet
For the 11kW IPV-11K48T, our starting recommendation is one 32kWh IPL-51628H. A recommended alternative is two 16kWh IPL-51314H batteries, giving 32kWh total and more current capability than a single 16kWh unit. The inverter’s own current ceiling still applies; compare the load estimates and increase storage if you need longer backup.
Which itel battery goes with each inverter?
Start with voltage family, then check power capability and communication. A 12.8V lithium battery is in the 12V family, 25.6V belongs to the 24V family, and 51.2V belongs to the 48V family. Those nominal labels reflect the lithium-cell configuration; they do not mean the battery stays at exactly that voltage while charging or discharging.
| Inverter family | Battery listings to assess | Pairing condition |
|---|---|---|
| 12V: 1.5kW | IPB-12100 · 1.28kWh | Match charge settings and continuous current. Do not promise full 1.5kW from one small battery. |
| 24V: 4kW Pro | IPW-25100 · 2.56kWh IPL-25200X · 5.12kWh | One IPW-25100 is limited by 100A discharge. Size the bank for both running load and start-up surges. |
| 48V: 6kW Pro, 6.6kW, single-phase 8/11/12kW and three-phase 8/12kW | IPW-51100 · 5.12kWh IPL-51200H · 10.24kWh IPL-51314H · 16kWh | 51.2V lithium is the relevant nominal family. Verify current, protocol, cable pinout and approved battery quantity. |
| 32kWh listing | View the listed 32kWh battery | 51.2V / 628Ah, 300A continuous discharge and up to 32 parallel units in the itel Solar technical table. Explore 1–4 units; inverter current limits and commissioning settings still apply. |
Voltage family is a shortlist, not a complete compatibility certificate. The inverter and battery must agree on charging limits, minimum voltage, BMS communication protocol, cable pinout and firmware settings. The approved number of parallel batteries and the installation’s cables, protection and current limits also matter. Do not create a higher-voltage bank by putting batteries in series unless the exact battery manual explicitly permits that configuration.
A 5.12kWh battery can be 25.6V or 51.2V. That is why the 24V IPL-25200X and 48V IPW-51100 cannot be chosen interchangeably just because their energy labels match. Read the companion itel battery guide for capacity, output-current and runtime examples.
Technical references: itel IPB-12100 manual, February 2026 · itel IPW-25100 manual · itel IPL-25200X manufacturer sheet (Solar Guide mirror) · itel IPW-51100 manual, June 2025 revision · itel IPL-51200H manufacturer datasheet · itel IPL-51314H manufacturer datasheet · itel Solar distributor: IPL-51628H technical specifications
Single phase, three phase and “hybrid” explained
Single-phase equipment supplies the appropriate single-phase circuit. A three-phase inverter is for an installation designed around three phases. A 12kW three-phase unit’s headline rating is its total rating, not 12kW available independently on each phase. Your installer must check per-phase loading and any allowed imbalance.
A hybrid inverter combines power-management functions for solar, battery and another supply, but features differ by model. Do not assume every product can export energy to the grid, operate without a battery, parallel with another unit or accept any generator. Confirm the exact manual and installation requirements for the function you need.
An IP rating describes the enclosure’s tested protection. It is not permission to mount any battery or inverter in rain, floodwater or direct sun. Follow the prescribed location, ventilation, clearance and temperature limits for each component; the battery can have a lower IP rating than the inverter beside it.
How to choose a complete system
- List your loads. Record running watts, starting demand and which appliances need to operate together. Separate essential backup circuits if appropriate.
- Choose the inverter. Match its continuous and surge capability, supply phase and installation conditions to that load list.
- Choose battery energy and output. Decide how many hours you want, then verify that the battery bank can also supply the required current.
- Design the PV array. Use the exact panel label, roof conditions, inverter input limits and charging needs.
- Confirm the whole quotation. Check whether panels, battery, protection devices, mounting, cables and installation are included. Product-only listings are not automatically complete systems.
A practical starting shortlist is the 12V 1.5kW model for modest essential loads, the 24V 4kW Pro for a larger essential-load design, and a suitably sized 48V system where the load survey calls for it. These are starting points, not blanket claims about appliance counts.
Can one inverter use two, three or four batteries?
Yes, where the exact battery supports that parallel bank. The number is governed by the battery’s approved parallel arrangement, the system’s voltage, BMS, charging settings and installation. It is not a fixed “one battery per inverter” rule.
For example, four matching 12.8V, 100Ah IPB-12100 batteries in parallel form a 12.8V, 400Ah bank: 5.12kWh nominal storage. They do not become 51.2V. That voltage family is a candidate for the 12V IPV-1K512U; the bank does not turn the inverter into a larger-power model. The battery manual permits four parallel units, but the supplied revision and its approved charging profile must be confirmed.
| Battery model | Documented parallel count | Charging allowance used here, per battery | What it means for this guide |
|---|---|---|---|
| IPB-12100 · 1.28kWh | 4 in the February 2026 manual | 20A recommended | 1–4 matching units can be explored. Uses 50A standard discharge; 90A is a 3-second rating in this manual. Conflicting datasheet revision must be resolved. |
| IPW-25100 · 2.56kWh | 15 in the datasheet | 50A standard | 1–4 units are below the documented bank count. A single unit limits the available battery power on a 4kW inverter. |
| IPL-25200X · 5.12kWh | 32 in the referenced datasheet | 100A recommended | 1–4 units are below that sheet’s count. Manual revisions differ in enclosure and communication details; match the delivered hardware. |
| IPW-51100 · 5.12kWh | 15 in the family datasheet | 50A standard | 1–4 matching units, subject to exact communication and protection design. |
| IPL-51200H · 10.24kWh | 32 in the datasheet; manual addresses 1–32 | 100A recommended | Two, three or four matching H units are within the battery-side count. The 6kW inverter still has a 120A solar-charge limit and 130A discharge limit. |
| IPL-51314H · 16kWh | 32 in the datasheet | 150A in the H-series settings table | More stored energy can mean more charging days. The inverter and BMS limits still apply. |
| IPL-51628H · 32kWh | 32 in the itel Solar technical table | 250A maximum continuous; capped by the inverter | Explore 1–4 matching units with 300A continuous discharge per unit. Inverter limits, BMS settings and the site design still govern actual output. |
Battery parallel and inverter parallel are different features. “No parallel” in an inverter specification normally concerns connecting multiple inverters together. It does not, by itself, prohibit an approved bank of parallel batteries connected to one inverter.
The selector checks published voltage and count limits, then calculates current and energy separately. It checks both nominal voltage and the published battery minimum: if only the nominal check passes, the result is labelled an energy estimate because the load can reach a current limit before the assumed reserve is reached. A load that exceeds the bank or inverter current allowance gets no runtime estimate. IPL-51628H calculations use the 300A discharge, 250A charge and 32-unit parallel ratings published in itel Solar’s technical table. A passing calculation is not a manufacturer-issued approval of every inverter/battery firmware combination.
The small IPB battery needs special attention: its manual lists Bluetooth monitoring, not a CAN/RS485 inverter data port. Do not assume it offers the same closed-loop communication as the H-series batteries. A supported configuration without that communication needs the correct manufacturer-approved voltage and current settings; do not guess an inverter’s lithium profile.
Sources: IPB-12100 manual, IPL-51200H manual, itel Solar IPL-51628H technical table, and the individual datasheets linked in the comparison. Limits refer to the referenced revision, not every unit with a similar name.
Why a bigger battery bank can need more than a day to recharge
Energy must come from somewhere. Adding batteries increases storage but does not increase sunlight, panel power or the inverter’s charging-current limit. The charging tool compares the energy needed to refill the bank from 20% to 100% with the solar power left after daytime appliances.
At the tool’s assumptions, one 590W panel can store about 0.42kW when appliances are off. Refilling four 1.28kWh batteries over that 80% range requires 4.10kWh: approximately 9.7 equivalent strong-sun hours, or 2.4 solar-day equivalents at four peak-sun-hours per day, before final charging taper. That assumes no night-time use. A sustained 500W appliance load already exceeds this panel’s estimated AC contribution, leaving no solar surplus for charging in the scenario.
“Peak-sun-hours” is an energy measure: a variable day’s sunlight expressed as an equivalent duration at the reference irradiance. It is not the number of hours between sunrise and sunset. Use a location-specific solar assessment when choosing the final system.
What makes a properly designed installation?
The calculator is a buying and learning aid. Standards compliance belongs to the complete design, installed equipment and commissioning record. The review uses manufacturer documents and publicly available standards scopes; it is not a clause-by-clause certification or a substitute for the full standards.
| Reference | Relevant design area | Evidence to request for your installation |
|---|---|---|
| IEC 62548-1:2023, with 2025 amendment | PV-array design, DC wiring, switching, protection and earthing | A string schedule with temperature-corrected voltages, current allowances, cable sizing and DC protection ratings. |
| IEC 60364-7-712:2025 | PV electrical installations, including storage and island-operation provisions | The distribution, earthing, neutral, isolation and protective-device design appropriate to the actual supply arrangement. |
| IEC 62446-1:2016 + A1:2018 | Documentation, inspection and commissioning of grid-connected PV systems | Applicable test results, labels, drawings, equipment records and the customer handover pack. Its stated scope is grid-connected PV. |
| IEC 62619:2022 | Safety requirements and tests for industrial lithium batteries, including stationary use | Evidence for the exact battery model. A standards logo or transport-test claim alone does not certify the installed system. |
| NEMSA renewable-energy installation competency scheme | Relevant installer competence in Nigeria | A contractor whose current certification covers the work, and confirmation of the applicable Nigerian requirements and inspection route. |
Protection must fit the fault as well as the normal load. Battery branches and the shared DC path need correctly coordinated protection and an adequate DC fault-interruption rating. Cable selection must consider current, length, voltage drop, installation conditions and temperature. Equal current paths help parallel batteries share load; if a battery disconnects, the remaining units must not be assumed to retain the original bank’s current capability.
Neutral-to-earth arrangements, residual-current protection and switching depend on the inverter and the site’s earthing system. Do not add a generic neutral-earth link or bond a DC conductor to earth by guesswork. Likewise, the word “hybrid” does not by itself authorise grid export; the selected operating mode, anti-islanding protection and connection requirements must be established for the installation.
Practical wiring reference: Victron’s battery-bank wiring guide. It explains shared-current paths; Victron product-specific limits are not used as itel compatibility limits.
Understanding the wiring, one connection at a time
A solar system has separate paths for panel power, battery power, household power and communication. Knowing the purpose of each path helps you understand an installer’s design. The diagrams below explain the principle; the terminal layout and installation procedure come from the exact equipment manuals.
A functional map, not a terminal diagram. Earthing, surge-protection connections, neutral arrangements and any changeover system are omitted for clarity and must be included in the installation design.
1. Panels go to PV. Batteries go to BAT.
PV means photovoltaic: electricity from the panels. The inverter’s MPPT controls that solar input. The battery connection is a different circuit, designed for the inverter’s battery-voltage family. Do not connect a panel string to the battery terminals or a battery to the PV input.
The inverter’s AC output supplies the designated circuits through a properly protected distribution board. Grid or generator input uses the connection and switching arrangement approved for that model. A three-phase model also needs correct phase allocation and load balancing. An inverter must never feed a house through a wall socket.
2. Series adds voltage. Parallel adds current.
Series is a chain. The positive terminal of one panel connects to the negative terminal of the next. The two free ends form the positive and negative ends of the string. With identical panels, voltages add while current stays at approximately one panel’s current.
Parallel joins matching strings side by side. Their positive ends join a positive path, and their negative ends join a negative path through the specified connection and protection arrangement. Currents add while voltage stays approximately the same. Never join the positive and negative terminals of the same panel together.
Explore the system map and interactive series/parallel example beside the solar selection above.
Use electrically matched panels in a series string. Parallel strings on the same tracker should have matching string lengths and suitable electrical characteristics. Separate MPPTs can handle separately designed groups, such as different roof orientations. Two separate MPPT inputs are not the same as joining two strings onto one tracker.
References: JA Solar bifacial-module installation manual; Jinko 605–630W module datasheet. The example arithmetic uses the 625W column.
3. Check all the limits, not just total panel watts
Panel quantity × panel watts must respect the permitted PV array power for the exact inverter.
The string must start the inverter, stay in its operating range and remain below the maximum PV voltage even in cold conditions.
Check operating current and short-circuit current for each MPPT. Parallel strings, bifacial gain and required design factors matter.
Vmp is voltage at the panel’s maximum-power point. Voc is open-circuit voltage, measured without a load; it is higher than Vmp. Imp is operating current at maximum power, while Isc is short-circuit current. These values answer different design questions and cannot be substituted for one another.
Why temperature matters: ten of the example Jinko panels have a combined Voc of 10 × 49.28V = 492.8V at 25°C. Using their −0.25%/°C Voc coefficient, at a hypothetical 10°C cell temperature that becomes approximately 511.3V, before other allowances. That exceeds a 500V input ceiling even though the array is only 6.25kWp. The installer must use the site’s design minimum temperature and the applicable tolerances; hot-weather Vmp also needs checking against the tracking range.
An inverter marked “30A + 20A” has two different tracker limits. It does not give permission to put 50A into either one. Likewise, a panel whose operating current already exceeds an input limit does not become suitable just because its wattage fits. The comparison table above lists the inverter limits; the installation manual supplies the remaining design requirements.
4. Two batteries: more storage at the correct voltage
10.24kWh nominal storage
In an approved parallel bank, voltage stays the same while amp-hour capacity adds. Two identical 51.2V, 100Ah batteries therefore store 10.24kWh in total. Putting those batteries in series would instead create a nominal 102.4V bank, which is unsuitable for these 48V-family inverter inputs.
Parallel installation needs supported matching batteries, appropriate protection on each battery branch, a suitable shared connection arrangement and balanced cable paths so units can share current properly. The inverter still has its own maximum battery current. Do not mix models, capacities, revisions or old and new units unless their manufacturer explicitly supports the combination.
The BMS communication cable lets the battery and inverter exchange status and charging information. It carries information, not the main battery power. A socket that resembles a network port is not evidence that an ordinary Ethernet cable or pinout is correct. Use the specified protocol, cable pinout, master/address settings and firmware for the exact equipment.
5. What else belongs in the installation?
- Panel mounting and DC cabling: properly secured mounting, compatible connectors and outdoor-rated PV cable, routed and supported for the installation conditions.
- DC protection and isolation: correctly rated PV isolation, required string protection, surge protection and battery branch protection. An AC-only breaker is not automatically suitable for DC.
- Battery connections: correctly sized conductors, terminals and any busbars, with connections tightened to the equipment’s specified torque.
- AC distribution and earthing: suitable overcurrent and residual-current protection, protective bonding and the correct neutral and changeover arrangement for the inverter and supply.
- Commissioning records: the final string plan, measured voltages, protection ratings, battery settings, circuit labels and the procedure for normal shutdown.
There is no single cable size, fuse size or switching sequence that fits all nine inverters. Cable length, current, installation method, temperature, fault protection and the exact manual determine those choices. Ask the installer to explain the drawing and show where each part of the design meets the equipment limits.
Panels can produce dangerous DC voltage whenever illuminated, even with grid power off. Do not unplug PV connectors under load. A qualified installer should verify polarity, insulation, protective connections and settings, then commission the system in the manufacturer’s prescribed sequence before testing loads and charging.
Installation references: itel Pro / 12kW inverter manual; itel IPW-51100 battery manual. These illustrate installation principles; use the manual for the exact model being installed.
Common questions
Can the 11kW inverter run my whole house?
Possibly, but only if your measured simultaneous load, starting demand, battery output, supply phase and installation are within the system’s limits. “Whole house” is not an electrical specification.
Can I add more solar panels later?
Often a system can be designed for expansion. Leave room in the PV power, voltage and current limits from the start, and check that the later panel strings remain electrically suitable.
Does a larger battery make my inverter more powerful?
It can extend runtime and an approved parallel bank may support more battery current, but it does not raise the inverter’s own AC-output rating.
What should I send CDcare before buying?
Send your appliance list, location, desired backup hours, whether the supply is single or three phase, and the exact model numbers of any equipment you already own. That makes a meaningful system assessment possible.
Ready to compare? Open any linked inverter, battery or panel above to view its CDcare listing. Then confirm a complete system design before installation.
Common questions about itel inverters
What is the difference between inverter kW and battery kWh?
Inverter kW describes the power it can supply at one time. Battery kWh describes stored energy. Backup time also depends on the load, usable battery capacity, conversion losses and current limits.
Can I use any solar panel with an itel inverter?
Wattage alone is not enough. The exact panel voltage and current, string arrangement, inverter MPPT range and maximum PV limits must all fit. Use the connection explorer above, then have an installer confirm the exact equipment and site design.
Where can I buy these itel inverters in Nigeria?
The comparison and planner link to each model on CDcare. Open a product to see its current price, availability and payment options.
Prepared by CDcare. Specifications and sources checked 9 October 2026. Calculations are planning estimates; the exact equipment manuals and a qualified installer determine the final system design.
